DXQ LCD Display
DXQ has 0.39~23.5 inch LCD display screens, including TFT LCD Display, AMOLED Display, Monochrome Display, Flexible LCD Display, etc., which are suitable for various products such as game consoles, monitors, industrial products, consumer electronics, etc. DXQ LCD Display has very clear display functions and response speeds, supports OEM&ODM customization, and can customize products according to user needs. Contact us for more product and logistics information. At the same time, we also have professional engineers and pre-sales and after-sales teams to escort your products.
DXQ Hot Product Data Sheet
| Size(Inch) | DXQ Type | Resolution | Brightness | Interface | Type | Contrast Ratio |
|---|---|---|---|---|---|---|
| 0.39 | B039FH8A0 | 1920x1080 | 300nits | MIPI/60pins | OLED | 10000:1 |
| 0.49 | VX049-FHP-NH3 | 1080x1920 | 300nits | MIPI/40pins | OLED | 1000:1 |
| 0.95 | DXQ0D9503-V2 | 120x240 | 800nits | SPI/30pins | OLED | 1000000:1 |
| 0.96 | TFT096H001 | 80x160 | 120nits | SPI/13pins | TFT | 600:1 |
| 1.2 | X120BLN02 | 390x390 | 350nits | MIPI/SPI/24pins | OLED | 10000:1 |
| 1.2 | DXQ120MYB2416A | 390x390 | 500nits | QSPI/24pins | OLED | 60000:1 |
| 1.39 | WJ014ZE-02A | 400x400 | 300nits | MIPI/24pins | OLED | 10000:1 |
| Click to view more sizes | ||||||
| 1.43 | DXQ1D4306 | 466x466 | 450nits | QSPI/24pins | OLED | 100000:1 |
| 1.47 | DXQ1D4702 | 172x320 | 300nits | SPI/10pins | TFT | 800:1 |
| 1.5 | WJ015ZE-01A | 120x240 | 350nits | MIPI/24pins | OLED | 10000:1 |
| 1.54 | DXQ1D54003 | 240x240 | 460nits | SPI/24pins | TFT | 900:1 |
| 1.6 | E1604AC61.A | 320x360 | 500nits | MIPI/SPI/38pins | OLED | 100000:1 |
| 1.78 | DXQ1D7802 | 368x448 | 500nits | MIPI/20pins | OLED | 10000:1 |
| 1.9 | DXQ1D9002 | 170x320 | 200nits | SPI/10pins | TFT | 900:1 |
| 2.0 | DXQ2D0002 | 240x320 | 450nits | MCU/22pins | TFT | 1000:1 |
| 2.4 | DXQ2D4002 | 240x320 | 250nits | SPI/18pins | TFT | 800:1 |
| 2.69 | DXQ2D69001 | 800x600 | 420nits | MIPI/30pins | OLED | 100000:1 |
| 2.8 | DXD2D8009 | 480x640 | 350nits | MIPI/24pins | TFT | 1000:1 |
| 2.9 | LS029B3SX04 | 1440x1440 | 150nits | MIPI/40pins | TFT | 600:1 |
| 3.49 | DXQ3D4902-V1 | 640x480 | 600nits | MIPI | TFT | 1200:1 |
| 3.92 | DXQ3D9202 | 1080x1240 | 520nits | MIPI/45pins | OLED | 100000:1 |
| 3.95 | DXQ3D9503 | 480x480 | 450nits | SPI/RGB/40pins | TFT | 1200:1 |
| 3.97 | DXQ3D9715 | 480x800 | 350nits | MIPI/30pins | TFT | 800:1 |
| 4.0 | G1323TC101FF-002 | 192x960 | 350nits | MIPI/30pins | FLEXIBLE | 17500:1 |
| 5.5 | DXQ5D5053 | 720x1280 | 300nits | MIPI/41pins | TFT | 1000:1 |
| 5.5 | G1548FH101GF-001 | 1080x1920 | 420nits | MIPI/40pins | OLED | 10000:1 |
| 6.0 | DXQ6D0005 | 1080x1920 | 450nits | MIPI | TFT | 1500:1 |
| 6.67 | WM6676Z21-7 | 2400x1080 | 500nits | MIPI/40pins | OLED | 500000:1 |
| 7.0 | DXQ7D0023 | 1080x1920 | 800nits | MIPI/39pins | OLED | 100000:1 |
| 8.0 | DXQ8D001 | 2480x1860 | 430nits | MIPI/SPI/46pins | OLED | 600000:1 |
| 10.3 | DXQ10D3001 | 7680x4320 | 0nits | MIPI/50pins | MONO | 450:1 |
| 11.0 | EB00QBE71.A | 2560x1600 | 800nits | MIPI/51pins | OLED | 1000000:1 |
| 12.8 | DXQ12D8001 | 5448x3064 | 0nits | eDP/40pins | MONO | 350:1 |
| 15.6 | DXQ15D60856 | 1920x1080 | 280nits | eDP/30pins | TFT | 800:1 |
| 18.5 | DXQ18D50766 | 1920x1080 | 300nits | LVDS/30pins | TFT | 1000:1 |
| 21.5 | DXQ21D50773 | 1920x1080 | 280nits | LVDS | TFT | 1000:1 |
| 23.8 | M238BMN463-M0202 | 1920x1080 | 400nits | LVDS | TFT | 1000:1 |
